Electric winches 8,500 lb, 9,500 lb, and 12,000 lb
Rated Line Pull
8500LBS (3856kgs) single line
Motor
3.2kw/4.3hp, permanent magnet
Control
Remote switch, 11.5ft(3.5m)lead
Gear train
Three stage
Gear train ratio
254:1
Freespooling Clutch
Rotating ring gear
Braking Action
Flanges brake
Drum Size
Cable
Overall Dimensions
Φ2.5″(64)mm×(8.8″)233.5mm
Φ8.3mmX28m
19.8″x6.3″x8.5″(503mm×160mm×217mm)
Electric winches 8,500 lb, 9,500 lb, and 12,000 lb
Introduction of the machine
1.3 stage planetary gearbox delivers the most reliable and durable performance of winch under the worst
condition.
2.Braking by flanges transmission.
3.Rotating ring gear clutch have the freespooling positioned actually for the rapid pay out of wire rope
with ease.
4.Installation ,operation and maintenance with ease.
5.It's total length is 520mm(20.5").
Rated Line Pull
8500LBS (3856kgs) single line
Motor
3.2kw/4.3hp, permanent magnet
Control
Remote switch, 11.5ft(3.5m)lead
Gear train
Three stage
Gear train ratio
254:1
Freespooling Clutch
Rotating ring gear
Braking Action
Flanges brake
Drum Size
Cable
Overall Dimensions
Φ2.5"(64)mm×(8.8")233.5mm
Φ8.3mmX28m
19.8"x6.3"x8.5"(503mm×160mm×217mm)
